FAG 6306-Z-N

FAG 6306-Z-N
FAG 6306-Z-N rulman resim 1
FAG 6306-Z-N rulman resim 2
Price: 21.02 $
Specifications
Brand FAG
Item Number 6306-Z-N FAG
Manufacturer Part Number 0167232280000
EAN 4012801073783
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 72
Width (B) MM 19
Inner (d) Inch 1.1811
Outer (D) Inch 2.8346
Width (B) Inch 0.748
Weight (kg) 0.343 kg
Product Properties
Bore C - Cylindrical Bore
Seal Z - Steel Seal on One Side
Cage Type S - Steel or Standard Cage
External Modification N - Snap Ring Groove in Outer Ring
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 19
Basic static load rating, radial (C 0r) 16200
Limiting speed (n G) 13700
Reference speed (n u03d1r) 10500
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Suffix description
Z Shield Of Pressed Sheet Steel On One Side Of The Bearing
N Snap Ring Groove In The Outer Ring
