FAG QJ305-XL-N2-MPA-P6-T42B Image 2
Visual product photo and picture of the product.
Price: 104.98 $
Specifications
Weight and Dimensions
| Inner (d) MM |
25 |
| Outer (D) MM |
62 |
| Width (B) MM |
17 |
| Inner (d) Inch |
0.9843 |
| Outer (D) Inch |
2.4409 |
| Width (B) Inch |
0.6693 |
| Weight (kg) |
0.28 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
N2 - 2 Locking Groove in Outer Ring |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
P6 Precision (Higher than Standard) |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Split inner ring |
Data from Schaeffler (medias)
| Width (b) mm |
17 |
| Basic static load rating, radial (C 0r) |
28500 |
| Limiting speed (n G) |
23300 |
| Reference speed (n u03d1r) |
9000 |
Suffix description
| XL |
X-Life |
| N2 |
Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer |
| MPA |
Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing) |
| P6 |
Dimensional And Running Accuracy To ISO Tolerance Class 6 (Better Than Normal) |
| T42B |
Four Point Bearings With Special Axial Clearance |
