FAG QJ305-XL-MPA

FAG QJ305-XL-MPA
FAG QJ305-XL-MPA rulman resim 1
FAG QJ305-XL-MPA rulman resim 2
FAG QJ305-XL-MPA rulman resim 3
FAG QJ305-XL-MPA rulman resim 4
Price: 57.25 $
Specifications
Brand FAG
Item Number QJ305-XL-MPA FAG
Manufacturer Part Number 0167424270000
Also known as QJ305-MPA
EAN 4012801012157
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 62
Width (B) MM 17
Inner (d) Inch 0.9843
Outer (D) Inch 2.4409
Width (B) Inch 0.6693
Weight (kg) 0.28 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 28500
Radial Dynamic Load Rating Cr (N) 43500
Basic static load rating, radial (C 0r) "28500.0000"
Limiting speed (n G) 23300
Reference speed (n u03d1r) 9000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ3..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
