FAG QJ215-XL-N2-MPA
Price: 201.76 $
Specifications
| Brand | FAG |
| Item Number | QJ215-XL-N2-MPA FAG |
| Manufacturer Part Number | 0388885210000 |
| Also known as |
QJ215-N2-MPA |
| EAN | 4012802004885 |
| Category | Four Point Contact Ball Bearing |
| Inner (d) MM | 75 |
| Outer (D) MM | 130 |
| Width (B) MM | 25 |
| Inner (d) Inch | 2.9528 |
| Outer (D) Inch | 5.1181 |
| Width (B) Inch | 0.9843 |
| Weight (kg) | 1.468 kg |
| Seal | No Seal |
| Cage Type | MA - Brass Cage, Centered on Outer Ring |
| External Modification | N2 - 2 Locking Groove in Outer Ring |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Split inner ring |
| Width (b) mm | 25 |
| Radial Static Load Rating C0r (N) | 122000 |
| Radial Dynamic Load Rating Cr (N) | 123000 |
| Basic static load rating, radial (C 0r) | "122000.0000" |
| Limiting speed (n G) | 10200 |
| Reference speed (n u03d1r) | 4550 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Four-point contact bearing QJ2..-XL-N2-MPA, inner ring split |
| XL | X-Life |
| N2 | Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer |
| MPA | Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing) |
