FAG 6215-Z-C3
Price: 51.77 $
Specifications
| Brand | FAG |
| Item Number | 6215-Z-C3 FAG |
| Manufacturer Part Number | 0191051770030 |
| Also known as |
6215-C-Z-C3 |
| EAN | 4012801277617 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 75 |
| Outer (D) MM | 130 |
| Width (B) MM | 25 |
| Inner (d) Inch | 2.9528 |
| Outer (D) Inch | 5.1181 |
| Width (B) Inch | 0.9843 |
| Weight (kg) | 1.18 kg |
| Bore | C - Cylindrical Bore |
| Seal | Z - Steel Seal on One Side |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| Width (b) mm | 25 |
| Radial Static Load Rating C0r (N) | 49000 |
| Radial Dynamic Load Rating Cr (N) | 70000 |
| Basic static load rating, radial (C 0r) | "49000.0000" |
| Limiting speed (n G) | 7800 |
| Reference speed (n u03d1r) | 5900 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearing 62..-Z, single row, cf. DIN 625-1 |
| Z | Shield Of Pressed Sheet Steel On One Side Of The Bearing |
| C3 | Internal Clearance Larger Than Normal |
