FAG QJ214-XL-TVP-C3 Image 4
Visual product photo and picture of the product.
Price: 105.90 $
Specifications
Weight and Dimensions
| Inner (d) MM |
70 |
| Outer (D) MM |
125 |
| Width (B) MM |
24 |
| Inner (d) Inch |
2.7559 |
| Outer (D) Inch |
4.9213 |
| Width (B) Inch |
0.9449 |
| Weight (kg) |
1.3 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
P - Plastic Molded Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Split inner ring |
Data from Schaeffler (medias)
| Width (b) mm |
24 |
| Radial Static Load Rating C0r (N) |
122000 |
| Radial Dynamic Load Rating Cr (N) |
123000 |
| Basic static load rating, radial (C 0r) |
"122000.0000" |
| Limiting speed (n G) |
7100 |
| Reference speed (n u03d1r) |
4600 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Four point contact bearings QJ2, main dimensions to DIN 628-4, separable, with split inner ring |
Suffix description
| XL |
X-Life |
| TVP |
Moulded Polyamide Window-Type Cage, Rolling Element Riding |
| C3 |
Internal Clearance Larger Than Normal |
