FAG QJ213-XL-N2-MPA

FAG QJ213-XL-N2-MPA
FAG QJ213-XL-N2-MPA rulman resim 1
FAG QJ213-XL-N2-MPA rulman resim 2
FAG QJ213-XL-N2-MPA rulman resim 3
FAG QJ213-XL-N2-MPA rulman resim 4
FAG QJ213-XL-N2-MPA rulman resim 5
Price: 161.47 $
Specifications
Brand FAG
Item Number QJ213-XL-N2-MPA FAG
Manufacturer Part Number 0390262720000
Also known as QJ213-N2-MPA
EAN 4012802344196
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 65
Outer (D) MM 120
Width (B) MM 23
Inner (d) Inch 2.5591
Outer (D) Inch 4.7244
Width (B) Inch 0.9055
Weight (kg) 1.2 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 23
Radial Static Load Rating C0r (N) 104000
Radial Dynamic Load Rating Cr (N) 106000
Basic static load rating, radial (C 0r) "104000.0000"
Limiting speed (n G) 11300
Reference speed (n u03d1r) 4900
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-N2-MPA, inner ring split
Suffix description
XL X-Life
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
