FAG 6213-H-SN-C3

FAG 6213-H-SN-C3
FAG 6213-H-SN-C3 rulman resim 1
FAG 6213-H-SN-C3 rulman resim 2
FAG 6213-H-SN-C3 rulman resim 3
FAG 6213-H-SN-C3 rulman resim 4
Price: 35.88 $
Specifications
Brand FAG
Item Number 6213-H-SN-C3 FAG
Manufacturer Part Number 3015314120030
Also known as 6213-C-C3
EAN 4064328303027
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 65
Outer (D) MM 120
Width (B) MM 23
Inner (d) Inch 2.5591
Outer (D) Inch 4.7244
Width (B) Inch 0.9055
Weight (kg) 0.997 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 23
Radial Static Load Rating C0r (N) 40150
Radial Dynamic Load Rating Cr (N) 57190
Basic static load rating, radial (C 0r) "40150.0000"
Limiting speed (n G) 7800
Reference speed (n u03d1r) 6200
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearings 62..-H, main dimensions to DIN 625-1
Suffix description
H Basic Quality
SN The Rings Of The Bearing Are Dimensional Stabilised To 120°C
C3 Internal Clearance Larger Than Normal
