FAG QJ212-XL-N2-MPA

FAG QJ212-XL-N2-MPA
FAG QJ212-XL-N2-MPA rulman resim 1
FAG QJ212-XL-N2-MPA rulman resim 2
FAG QJ212-XL-N2-MPA rulman resim 3
FAG QJ212-XL-N2-MPA rulman resim 4
Price: 144.82 $
Specifications
Brand FAG
Item Number QJ212-XL-N2-MPA FAG
Manufacturer Part Number 0192606360000
Also known as QJ212-N2-MPA
EAN 4026677024763
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 60
Outer (D) MM 110
Width (B) MM 22
Inner (d) Inch 2.3622
Outer (D) Inch 4.3307
Width (B) Inch 0.8661
Weight (kg) 0.945 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 22
Radial Static Load Rating C0r (N) 87000
Radial Dynamic Load Rating Cr (N) 94000
Basic static load rating, radial (C 0r) "87000.0000"
Limiting speed (n G) 12300
Reference speed (n u03d1r) 5400
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-N2-MPA, inner ring split
Suffix description
XL X-Life
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
