FAG 6212-J20AB-C3

FAG 6212-J20AB-C3
FAG 6212-J20AB-C3 rulman resim 1
FAG 6212-J20AB-C3 rulman resim 2
FAG 6212-J20AB-C3 rulman resim 3
FAG 6212-J20AB-C3 rulman resim 4
Price: 290.09 $
Specifications
Brand FAG
Item Number 6212-J20AB-C3 FAG
Manufacturer Part Number 0704892110030
EAN 4047643291033
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 60
Outer (D) MM 110
Width (B) MM 22
Inner (d) Inch 2.3622
Outer (D) Inch 4.3307
Width (B) Inch 0.8661
Weight (kg) 0.791 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment J20AB
Data from Schaeffler (medias)
Width (b) mm 22
Radial Static Load Rating C0r (N) 36500
Radial Dynamic Load Rating Cr (N) 57000
Basic static load rating, radial (C 0r) "36500.0000"
Limiting speed (n G) 9300
Reference speed (n u03d1r) 6800
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 62..-J20AB, single row, cf. DIN 625-1
Suffix description
J20AB Puncture Voltage: 1.000vDC - Operating Environment: Dry, Damp - Layer Thickness: 100u03bcm - Possible Dimensions: 70mmu20131400mm Outside Diameter
C3 Internal Clearance Larger Than Normal
