FAG QJ212-N2-MPA-F59-C4

FAG QJ212-N2-MPA-F59-C4
FAG QJ212-N2-MPA-F59-C4 rulman resim 1
FAG QJ212-N2-MPA-F59-C4 rulman resim 2
FAG QJ212-N2-MPA-F59-C4 rulman resim 3
FAG QJ212-N2-MPA-F59-C4 rulman resim 4
Price: 152.53 $
Specifications
Brand FAG
Item Number QJ212-N2-MPA-F59-C4 FAG
Also known as QJ212N2MA/C4B20
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 60
Outer (D) MM 110
Width (B) MM 22
Inner (d) Inch 2.3622
Outer (D) Inch 4.3307
Width (B) Inch 0.8661
Weight (kg) 0.99 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play C4 Internal Play (Higher than C3)
Precision A2 - Reduced Width Tolerance
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Suffix description
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
F59 Replaced By
H68 Bearing And Bearing Parts For Voith Getriebe KG, Heidenheim; For Special Cage Design, Width Tolerance, Radial Runout And Bearing Clearance See Specifications
C4 Bearing Internal Clearance Greater Than C3
