FAG QJ209-XL-MPA-T42F

FAG QJ209-XL-MPA-T42F
FAG QJ209-XL-MPA-T42F rulman resim 1
FAG QJ209-XL-MPA-T42F rulman resim 2
FAG QJ209-XL-MPA-T42F rulman resim 3
FAG QJ209-XL-MPA-T42F rulman resim 4
Price: 88.78 $
Specifications
Brand FAG
Item Number QJ209-XL-MPA-T42F FAG
Manufacturer Part Number 0167422654381
Also known as QJ209-MPA-T42F
EAN 4026677877925
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.515 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Special Axial Clearance
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 19
Radial Static Load Rating C0r (N) 53000
Radial Dynamic Load Rating Cr (N) 63000
Limiting speed (n G) 16200
Reference speed (n u03d1r) 7000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
T42F Four Point Bearings With Special Axial Clearance
