FAG QJ209-XL-MPA-T42A

FAG QJ209-XL-MPA-T42A
FAG QJ209-XL-MPA-T42A rulman resim 1
FAG QJ209-XL-MPA-T42A rulman resim 2
FAG QJ209-XL-MPA-T42A rulman resim 3
FAG QJ209-XL-MPA-T42A rulman resim 4
FAG QJ209-XL-MPA-T42A rulman resim 5
Price: 79.90 $
Specifications
Brand FAG
Item Number QJ209-XL-MPA-T42A FAG
Manufacturer Part Number 0167422654380
Also known as QJ209-MPA-T42A
EAN 4026677796455
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.515 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C2 Internal Play (Less than Cn)
Precision Special Axial Clearance
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 19
Radial Static Load Rating C0r (N) 53000
Radial Dynamic Load Rating Cr (N) 63000
Basic static load rating, radial (C 0r) "53000.0000"
Limiting speed (n G) 16200
Reference speed (n u03d1r) 7000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
T42A Special Axial C2 Clearance
