FAG QJ209-XL-MPA-C3

FAG QJ209-XL-MPA-C3
FAG QJ209-XL-MPA-C3 rulman resim 1
FAG QJ209-XL-MPA-C3 rulman resim 2
FAG QJ209-XL-MPA-C3 rulman resim 3
FAG QJ209-XL-MPA-C3 rulman resim 4
Price: 67.22 $
Specifications
Brand FAG
Item Number QJ209-XL-MPA-C3 FAG
Manufacturer Part Number 0167422650030
Also known as QJ209-MPA-C3
EAN 4012801012942
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.515 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 19
Radial Static Load Rating C0r (N) 53000
Radial Dynamic Load Rating Cr (N) 63000
Basic static load rating, radial (C 0r) "53000.0000"
Limiting speed (n G) 16200
Reference speed (n u03d1r) 7000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
C3 Internal Clearance Larger Than Normal
