FAG QJ208-XL-N2-MPA-T42B

FAG QJ208-XL-N2-MPA-T42B
FAG QJ208-XL-N2-MPA-T42B rulman resim 1
FAG QJ208-XL-N2-MPA-T42B rulman resim 2
FAG QJ208-XL-N2-MPA-T42B rulman resim 3
FAG QJ208-XL-N2-MPA-T42B rulman resim 4
Price: 75.79 $
Specifications
Brand FAG
Item Number QJ208-XL-N2-MPA-T42B FAG
Manufacturer Part Number 0390252844381
Also known as QJ208-N2-MPA-T42B
EAN 4026677108876
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 80
Width (B) MM 18
Inner (d) Inch 1.5748
Outer (D) Inch 3.1496
Width (B) Inch 0.7087
Weight (kg) 0.441 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play Cn Normal Internal Play
Precision Special Axial Clearance
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 18
Radial Static Load Rating C0r (N) 46500
Radial Dynamic Load Rating Cr (N) 58000
Limiting speed (n G) 17500
Reference speed (n u03d1r) 7500
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-N2-MPA, inner ring split
Suffix description
XL X-Life
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
T42B Four Point Bearings With Special Axial Clearance
