FAG QJ208-XL-N2-MPA-F59-C4 Image 3
Visual product photo and picture of the product.
Price: 92.48 $
Specifications
Weight and Dimensions
| Inner (d) MM |
40 |
| Outer (D) MM |
80 |
| Width (B) MM |
18 |
| Inner (d) Inch |
1.5748 |
| Outer (D) Inch |
3.1496 |
| Width (B) Inch |
0.7087 |
| Weight (kg) |
0.45 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
N2 - 2 Locking Groove in Outer Ring |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
A2 - Reduced Width Tolerance |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Split inner ring |
Data from Schaeffler (medias)
| Width (b) mm |
18 |
| Basic static load rating, radial (C 0r) |
46500 |
| Limiting speed (n G) |
17500 |
| Reference speed (n u03d1r) |
7500 |
Suffix description
| XL |
X-Life |
| N2 |
Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer |
| MPA |
Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing) |
| F59 |
Replaced By |
| H68 |
Bearing And Bearing Parts For Voith Getriebe KG, Heidenheim; For Special Cage Design, Width Tolerance, Radial Runout And Bearing Clearance See Specifications |
| C4 |
Bearing Internal Clearance Greater Than C3 |
