FAG QJ207-XL-N2-MPA-T42A

FAG QJ207-XL-N2-MPA-T42A
FAG QJ207-XL-N2-MPA-T42A rulman resim 1
FAG QJ207-XL-N2-MPA-T42A rulman resim 2
FAG QJ207-XL-N2-MPA-T42A rulman resim 3
FAG QJ207-XL-N2-MPA-T42A rulman resim 4
Price: 79.11 $
Specifications
Brand FAG
Item Number QJ207-XL-N2-MPA-T42A FAG
Manufacturer Part Number 0390252254380
Also known as QJ207-N2-MPA-T42A
EAN 4012801315555
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 72
Width (B) MM 17
Inner (d) Inch 1.378
Outer (D) Inch 2.8346
Width (B) Inch 0.6693
Weight (kg) 0.35 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play C2 Internal Play (Less than Cn)
Precision Special Axial Clearance
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 35500
Radial Dynamic Load Rating Cr (N) 45000
Basic static load rating, radial (C 0r) "35500.0000"
Limiting speed (n G) 19800
Reference speed (n u03d1r) 8500
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-N2-MPA, inner ring split
Suffix description
XL X-Life
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
T42A Special Axial C2 Clearance
