FAG 6207-N-C3

FAG 6207-N-C3
FAG 6207-N-C3 rulman resim 1
FAG 6207-N-C3 rulman resim 2
FAG 6207-N-C3 rulman resim 3
FAG 6207-N-C3 rulman resim 4
FAG 6207-N-C3 rulman resim 5
FAG 6207-N-C3 rulman resim 6
Price: 10.10 $
Specifications
Brand FAG
Item Number 6207-N-C3 FAG
Manufacturer Part Number 0167203180030
EAN 4012801069694
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 72
Width (B) MM 17
Inner (d) Inch 1.378
Outer (D) Inch 2.8346
Width (B) Inch 0.6693
Weight (kg) 0.283 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type S - Steel or Standard Cage
External Modification N - Snap Ring Groove in Outer Ring
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 15300
Radial Dynamic Load Rating Cr (N) 27500
Basic static load rating, radial (C 0r) "15300.0000"
Limiting speed (n G) 13800
Reference speed (n u03d1r) 10400
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 62..-N, single row, cf. DIN 625-1
Suffix description
N Snap Ring Groove In The Outer Ring
C3 Internal Clearance Larger Than Normal
