FAG QJ207-XL-MPA-S1-T42A

FAG QJ207-XL-MPA-S1-T42A
FAG QJ207-XL-MPA-S1-T42A rulman resim 1
FAG QJ207-XL-MPA-S1-T42A rulman resim 2
FAG QJ207-XL-MPA-S1-T42A rulman resim 3
FAG QJ207-XL-MPA-S1-T42A rulman resim 4
FAG QJ207-XL-MPA-S1-T42A rulman resim 5
Price: 80.51 $
Specifications
Brand FAG
Item Number QJ207-XL-MPA-S1-T42A FAG
Manufacturer Part Number 0388997014380
Also known as QJ207-MPA-S1-T42A
EAN 4012801315517
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 72
Width (B) MM 17
Inner (d) Inch 1.378
Outer (D) Inch 2.8346
Width (B) Inch 0.6693
Weight (kg) 0.35 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C2 Internal Play (Less than Cn)
Precision Special Axial Clearance
Heat Stabilization S1 - Temperatures up to 200 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 35500
Radial Dynamic Load Rating Cr (N) 45000
Basic static load rating, radial (C 0r) "35500.0000"
Limiting speed (n G) 19800
Reference speed (n u03d1r) 8500
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ2..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
S1 Bearing Rings Or Washers Dimensionally Stabilized For Use At Operating Temperatures Up To +200°C (392°F)
T42A Special Axial C2 Clearance
