FAG QJ1022-N2-MPA-F59-C4 Image 2
Visual product photo and picture of the product.
Price: 522.78 $
Specifications
Weight and Dimensions
| Inner (d) MM |
110 |
| Outer (D) MM |
170 |
| Width (B) MM |
28 |
| Inner (d) Inch |
4.3307 |
| Outer (D) Inch |
6.6929 |
| Width (B) Inch |
1.1024 |
| Weight (kg) |
2.5 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
N2 - 2 Locking Groove in Outer Ring |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
A2 - Reduced Width Tolerance |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Split inner ring |
Data from Schaeffler (medias)
| Width (b) mm |
28 |
| Radial Static Load Rating C0r (N) |
184000 |
| Radial Dynamic Load Rating Cr (N) |
138000 |
| Limiting speed (n G) |
6900 |
| Reference speed (n u03d1r) |
3350 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Four-point contact bearing QJ10..-N2-MPA, inner ring split |
Suffix description
| N2 |
Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer |
| MPA |
Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing) |
| F59 |
Replaced By |
| H68 |
Bearing And Bearing Parts For Voith Getriebe KG, Heidenheim; For Special Cage Design, Width Tolerance, Radial Runout And Bearing Clearance See Specifications |
| C4 |
Bearing Internal Clearance Greater Than C3 |
