FAG NUP309-E-XL-N-M1-C3 Image 2
Visual product photo and picture of the product.
Price: 169.27 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
100 |
| Width (B) MM |
25 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
3.937 |
| Width (B) Inch |
0.9843 |
| Weight (kg) |
1.04 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
N - Snap Ring Groove in Outer Ring |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
25 |
| Basic static load rating, radial (C 0r) |
99000 |
| Limiting speed (n G) |
12800 |
| Reference speed (n u03d1r) |
6400 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
Suffix description
| E |
Increased Load Capacity |
| XL |
X-Life |
| N |
Snap Ring Groove In The Outer Ring |
| M1 |
Solid Brass Cage, Two Piece, Roller Guided |
| C3 |
Internal Clearance Larger Than Normal |
