FAG NUP221-E-XL-M1-F1-C3 Image 5
Visual product photo and picture of the product.
Price: 719.03 $
Specifications
Weight and Dimensions
| Inner (d) MM |
105 |
| Outer (D) MM |
190 |
| Width (B) MM |
36 |
| Inner (d) Inch |
4.1339 |
| Outer (D) Inch |
7.4803 |
| Width (B) Inch |
1.4173 |
| Weight (kg) |
3.7 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Bearings for Traction Motors |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
36 |
| Basic static load rating, radial (C 0r) |
320000 |
| Limiting speed (n G) |
6500 |
| Reference speed (n u03d1r) |
3400 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
Suffix description
| E |
Increased Load Capacity |
| XL |
X-Life |
| M1 |
Solid Brass Cage, Two Piece, Roller Guided |
| F1 |
FAG Manufacturing And Inspection Specification For Cylindrical Roller Bearings In Traction Motors Which Considers, Among Others, The Requirements According To Din 43283 "Cylindrical Roller Bearings For Electric Traction" |
| C3 |
Internal Clearance Larger Than Normal |
