FAG NU316-E-XL-M1A
Price: 278.00 $
Specifications
| Brand | FAG |
| Item Number | NU316-E-XL-M1A FAG |
| Manufacturer Part Number | 0192487090000 |
| Also known as |
NU316-E-M1A |
| EAN | 4012801400428 |
| Category | Cylindrical Roller Bearing Single Row |
| Inner (d) MM | 80 |
| Outer (D) MM | 170 |
| Width (B) MM | 39 |
| Inner (d) Inch | 3.1496 |
| Outer (D) Inch | 6.6929 |
| Width (B) Inch | 1.5354 |
| Weight (kg) | 4.32 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | MA - Brass Cage, Centered on Outer Ring |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 39 |
| Radial Static Load Rating C0r (N) | 275000 |
| Radial Dynamic Load Rating Cr (N) | 300000 |
| Basic static load rating, radial (C 0r) | "275000.0000" |
| Limiting speed (n G) | 7200 |
| Reference speed (n u03d1r) | 4100 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Cylindrical roller bearing NU..-E-XL-M1A, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU |
| E | Increased Load Capacity |
| XL | X-Life |
| M1A | Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring |
