FAG 6316-RSR-C3
Price: 136.91 $
Specifications
| Brand | FAG |
| Item Number | 6316-RSR-C3 FAG |
| Manufacturer Part Number | 0384057330030 |
| EAN | 4012801280921 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 80 |
| Outer (D) MM | 170 |
| Width (B) MM | 39 |
| Inner (d) Inch | 3.1496 |
| Outer (D) Inch | 6.6929 |
| Width (B) Inch | 1.5354 |
| Weight (kg) | 3.59 kg |
| Bore | C - Cylindrical Bore |
| Seal | RS - Rubber Seal on One Side |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| Width (b) mm | 39 |
| Radial Static Load Rating C0r (N) | 87000 |
| Radial Dynamic Load Rating Cr (N) | 131000 |
| Basic static load rating, radial (C 0r) | "87000.0000" |
| Limiting speed (n G) | 2470 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearing 63..-RSR, single row, cf. DIN 625-1 |
| RSR | One Seal, Buna-N Rubber, Radial Type |
| C3 | Internal Clearance Larger Than Normal |
