FAG NU214-E-XL-JP3-C3 Image 2
Visual product photo and picture of the product.
Price: 108.73 $
Specifications
Weight and Dimensions
| Inner (d) MM |
70 |
| Outer (D) MM |
125 |
| Width (B) MM |
24 |
| Inner (d) Inch |
2.7559 |
| Outer (D) Inch |
4.9213 |
| Width (B) Inch |
0.9449 |
| Weight (kg) |
1.17 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
Suffix description
| E |
Increased Load Capacity |
| XL |
X-Life |
| JP3 |
Applications With Cylindrical Roller Bearings With A Bearing Outer Diameter >90mm Wil Contain JP3 Sheet Steel Cage With Optimized Sheet Thickness, Improved Roller Guidance And Roller Retention, And Increased Oil Or Grease Flow |
| C3 |
Internal Clearance Larger Than Normal |
