FAG NU213-E-XL-M1-C4

FAG NU213-E-XL-M1-C4
FAG NU213-E-XL-M1-C4 rulman resim 1
FAG NU213-E-XL-M1-C4 rulman resim 2
FAG NU213-E-XL-M1-C4 rulman resim 3
FAG NU213-E-XL-M1-C4 rulman resim 4
FAG NU213-E-XL-M1-C4 rulman resim 5
Price: 181.24 $
Specifications
Brand FAG
Item Number NU213-E-XL-M1-C4 FAG
Manufacturer Part Number 0167378490040
Also known as NU213-E-M1-C4
EAN 4012801179379
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 65
Outer (D) MM 120
Width (B) MM 23
Inner (d) Inch 2.5591
Outer (D) Inch 4.7244
Width (B) Inch 0.9055
Weight (kg) 1.17 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 23
Radial Static Load Rating C0r (N) 120000
Radial Dynamic Load Rating Cr (N) 128000
Basic static load rating, radial (C 0r) "120000.0000"
Limiting speed (n G) 10600
Reference speed (n u03d1r) 4900
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NU..-E-XL-M1, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU
Suffix description
E Increased Load Capacity
XL X-Life
M1 Solid Brass Cage, Two Piece, Roller Guided
C4 Bearing Internal Clearance Greater Than C3
