FAG NU207-E-XL-TVP2-C4

FAG NU207-E-XL-TVP2-C4
FAG NU207-E-XL-TVP2-C4 rulman resim 1
FAG NU207-E-XL-TVP2-C4 rulman resim 2
FAG NU207-E-XL-TVP2-C4 rulman resim 3
FAG NU207-E-XL-TVP2-C4 rulman resim 4
Price: 42.95 $
Specifications
Brand FAG
Item Number NU207-E-XL-TVP2-C4 FAG
Manufacturer Part Number 0167376440040
Also known as NU207-E-TVP2-C4
EAN 4026677585868
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 72
Width (B) MM 17
Inner (d) Inch 1.378
Outer (D) Inch 2.8346
Width (B) Inch 0.6693
Weight (kg) 0.302 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type P - Plastic Molded Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 50000
Radial Dynamic Load Rating Cr (N) 59000
Basic static load rating, radial (C 0r) "50000.0000"
Limiting speed (n G) 14100
Reference speed (n u03d1r) 8100
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NU..-E-XL-TVP2, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU
Suffix description
E Increased Load Capacity
XL X-Life
TVP2 Solid Window Cage Made From Glass Fibre Reinforced Polyamide PA66. Roller Riding
C4 Bearing Internal Clearance Greater Than C3
