FAG NNU4934-S-M-SP-C2 Image 3
Visual product photo and picture of the product.
Price: 1,610.47 $
Specifications
Weight and Dimensions
| Inner (d) MM |
170 |
| Outer (D) MM |
230 |
| Width (B) MM |
60 |
| Inner (d) Inch |
6.6929 |
| Outer (D) Inch |
9.0551 |
| Width (B) Inch |
2.3622 |
| Weight (kg) |
7.6 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
W33 |
| Radial Internal Play |
C2 Internal Play (Less than Cn) |
| Precision |
SP - Precision Higher than P4S |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
60 |
| Basic static load rating, radial (C 0r) |
700000 |
| Fatigue load limit, radial (C ur) |
85000 |
| Limiting speed for grease lubrication (n G Grease) |
3300 |
| Limiting speed for oil lubrication (n G Oil) |
3850 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
Suffix description
| S |
Lubrication Groove And Three Holes In Bearing Outer Ring |
| M |
Solid Brass Cage, Roller Guided |
| SP |
Special Precision Class For Machine Tool Bearings: Dimensional Accuracy Approximately To P5, Running Accuracy Approximately To P4 |
| C2 |
Bearing Internal Clearance Smaller Than Normal |
