FAG NN3030-AS-K-M-SP Image 4
Visual product photo and picture of the product.
Price: 1,435.61 $
Specifications
Weight and Dimensions
| Inner (d) MM |
150 |
| Outer (D) MM |
225 |
| Width (B) MM |
56 |
| Inner (d) Inch |
5.9055 |
| Outer (D) Inch |
8.8583 |
| Width (B) Inch |
2.2047 |
| Weight (kg) |
7.4 kg
|
Product Properties
| Bore |
K - 1:12 Tapered Bore (Standard for Most Types) |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
SP - Precision Higher than P4S |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
56 |
| Radial Static Load Rating C0r (N) |
590000 |
| Radial Dynamic Load Rating Cr (N) |
335000 |
| Basic static load rating, radial (C 0r) |
"590000.0000" |
| Fatigue load limit, radial (C ur) |
73000 |
| Limiting speed for grease lubrication (n G Grease) |
3650 |
| Limiting speed for oil lubrication (n G Oil) |
4250 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
| Medias description |
Cylindrical roller bearings NN30..-AS-K-M-SP, main dimensions to DIN 5412-4, non-locating bearing, double row, with tapered bore, taper 1:12, separable, with cage, reduced radial internal clearance, restricted tolerances |
Suffix description
| A |
Cylindrical Roller Bearings, Parts Interchangeable |
| S |
Lubrication Groove And Three Holes In Bearing Outer Ring |
| K |
Tapered Bore, Taper 1:12 |
| M |
Solid Brass Cage, Roller Guided |
| SP |
Super Precision Specification, Tolerance Class SP, Radial Clearance C1 |
