FAG NN3028-AS-M-SP Image 4
Visual product photo and picture of the product.
Price: 1,062.19 $
Specifications
Weight and Dimensions
| Inner (d) MM |
140 |
| Outer (D) MM |
210 |
| Width (B) MM |
53 |
| Inner (d) Inch |
5.5118 |
| Outer (D) Inch |
8.2677 |
| Width (B) Inch |
2.0866 |
| Weight (kg) |
6.16 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
SP - Precision Higher than P4S |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
53 |
| Radial Static Load Rating C0r (N) |
520000 |
| Radial Dynamic Load Rating Cr (N) |
300000 |
| Basic static load rating, radial (C 0r) |
"520000.0000" |
| Fatigue load limit, radial (C ur) |
64000 |
| Limiting speed for grease lubrication (n G Grease) |
3900 |
| Limiting speed for oil lubrication (n G Oil) |
4600 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
| Medias description |
Cylindrical roller bearing NN..-AS-M-SP, with cage, two-row, non-locating bearing, 0 ribs on outer ring (smooth), 3 ribs on inner ring, type NN |
Suffix description
| A |
Cylindrical Roller Bearings, Parts Interchangeable |
| S |
Lubrication Groove And Three Holes In Bearing Outer Ring |
| M |
Solid Brass Cage, Roller Guided |
| SP |
Super Precision Specification, Tolerance Class SP, Radial Clearance C1 |
