FAG NN3028-AS-K-M-SP-J15Q

FAG NN3028-AS-K-M-SP-J15Q
FAG NN3028-AS-K-M-SP-J15Q rulman resim 1
Price: 1,152.80 $
Specifications
Brand FAG
Item Number NN3028-AS-K-M-SP-J15Q FAG
Manufacturer Part Number 0192313504300
EAN 4012801581660
Category Cylindrical Roller Bearing Double Row
Weight and Dimensions
Inner (d) MM 140
Outer (D) MM 210
Width (B) MM 53
Inner (d) Inch 5.5118
Outer (D) Inch 8.2677
Width (B) Inch 2.0866
Weight (kg) 6.16 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision SP - Precision Higher than P4S
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 53
Basic static load rating, radial (C 0r) 520000
Fatigue load limit, radial (C ur) 64000
Limiting speed for grease lubrication (n G Grease) 3900
Limiting speed for oil lubrication (n G Oil) 4600
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Suffix description
A Cylindrical Roller Bearings, Parts Interchangeable
S Lubrication Groove And Three Holes In Bearing Outer Ring
K Tapered Bore, Taper 1:12
M Solid Brass Cage, Roller Guided
SP Super Precision Specification, Tolerance Class SP, Radial Clearance C1
J15Q Marking Specifications Of Measured Values
