FAG 23028-E1-XL-TVPB-C4

FAG 23028-E1-XL-TVPB-C4
FAG 23028-E1-XL-TVPB-C4 rulman resim 1
FAG 23028-E1-XL-TVPB-C4 rulman resim 2
FAG 23028-E1-XL-TVPB-C4 rulman resim 3
FAG 23028-E1-XL-TVPB-C4 rulman resim 4
FAG 23028-E1-XL-TVPB-C4 rulman resim 5
FAG 23028-E1-XL-TVPB-C4 rulman resim 6
FAG 23028-E1-XL-TVPB-C4 rulman resim 7
FAG 23028-E1-XL-TVPB-C4 rulman resim 8
Price: 420.60 $
Specifications
Brand FAG
Item Number 23028-E1-XL-TVPB-C4 FAG
Manufacturer Part Number 0190010700040
Also known as 23028-E1-TVPB-C4
EAN 4026677871473
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 140
Outer (D) MM 210
Width (B) MM 53
Inner (d) Inch 5.5118
Outer (D) Inch 8.2677
Width (B) Inch 2.0866
Weight (kg) 6.04 kg
Product Properties
Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 53
Radial Static Load Rating C0r (N) 800000
Radial Dynamic Load Rating Cr (N) 570000
Basic static load rating, radial (C 0r) "800000.0000"
Limiting speed (n G) 3450
Reference speed (n u03d1r) 2390
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 230..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C4 Bearing Internal Clearance Greater Than C3
