FAG NN3012-D-TVP-SP-XL
Price: 277.39 $
Specifications
| Brand | FAG |
| Item Number | NN3012-D-TVP-SP-XL FAG |
| Manufacturer Part Number | 0929766030000 |
| Also known as |
NN3012-D-TVP-SP |
| EAN | 4054371105891 |
| Category | Cylindrical Roller Bearing Double Row |
| Inner (d) MM | 60 |
| Outer (D) MM | 95 |
| Width (B) MM | 26 |
| Inner (d) Inch | 2.3622 |
| Outer (D) Inch | 3.7402 |
| Width (B) Inch | 1.0236 |
| Weight (kg) | 0.672 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | P - Plastic Molded Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | SP - Precision Higher than P4S |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 26 |
| Radial Static Load Rating C0r (N) | 106000 |
| Radial Dynamic Load Rating Cr (N) | 87000 |
| Basic static load rating, radial (C 0r) | "106000.0000" |
| Fatigue load limit, radial (C ur) | 17400 |
| Limiting speed for grease lubrication (n G Grease) | 11300 |
| Limiting speed for oil lubrication (n G Oil) | 13300 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Cylindrical roller bearing NN..-D-TVP-SP-XL, with cage, two-row, non-locating bearing, 0 ribs on outer ring (smooth), 3 ribs on inner ring, type NN |
| D | Bearings With A Modified Internal Construction And The Suffix D Do Not Have A Lubrication Hole Or Lubrication Groove As Standard |
| TVP | Moulded Polyamide Window-Type Cage, Rolling Element Riding |
| SP | Super Precision Specification, Tolerance Class SP, Radial Clearance C1 |
| XL | X-Life |
INA SL183012-A-XL-C3
0.68 kg
60x95x26 mm
INA SL183012-A-XL
0.68 kg
60x95x26 mm
INA SL18-3012
0.68 kg
60x95x26 mm
INA SL18-3012A XL
0.68 kg
60x95x26 mm
INA SL18-3012A C3
0.68 kg
60x95x26 mm
INA SL18-3012C3
0.68 kg
60x95x26 mm
SKF NCF3012V
0.68 kg
60x95x26 mm
SKF NCF3012CV/C3
0.68 kg
60x95x26 mm
INA SL183012-A-C3
0.68 kg
60x95x26 mm
INA SL183012-A
0.68 kg
60x95x26 mm
INA SL18-3012A
0.68 kg
60x95x26 mm
IDC/Interprecise Donath GmbH NCF3012V
0.68 kg
60x95x26 mm
IDC/Interprecise Donath GmbH NCF3012V C3
0.68 kg
60x95x26 mm
NKE NCF3012-V-C3
0.68 kg
60x95x26 mm
ZEN NCF3012-V-C3
0.68 kg
60x95x26 mm
Rollway NCF3012CV
0.68 kg
60x95x26 mm
APB/Austria Precision Bearing NCF3012V
0.68 kg
60x95x26 mm
Neutral NCF3012V
0.68 kg
60x95x26 mm
FAG NN3012-D-K-TVP-SP-XL
0.66 kg
60x95x26 mm
SKF NN3012KTN/SPW33
0.66 kg
60x95x26 mm
SKF NN3012TN/SP
0.672 kg
60x95x26 mm
SKF NN3012KTN/SP
0.66 kg
60x95x26 mm
SKF NN3012TN/SPW33
0.672 kg
60x95x26 mm
NTN NN3012C1NAP5
0.672 kg
60x95x26 mm
NSK NN3012TBKRE44CC0P4
0.693 kg
60x95x26 mm
Nachi NN3012M2 MY C/10 P4
0.672 kg
60x95x26 mm
NTN NN3012KC1NAP5
0.672 kg
60x95x26 mm
Nachi NN3012M2 K C9NA P4
0.693 kg
60x95x26 mm
FLT NN3012K TNG P51
0.672 kg
60x95x26 mm
ZVL NN3012 K P51 NA W33
0.672 kg
60x95x26 mm
FLT NN3012K TNG P41
0.672 kg
60x95x26 mm
FAG NN3012ASK-M-SP
0.66 kg
60x95x26 mm
FAG NN3012ASK-M-UP
0.66 kg
60x95x26 mm
FAG NN3012K
0.66 kg
60x95x26 mm
FAG NN3012-AS-M-SP
0.672 kg
60x95x26 mm
