FAG NN3012-D-K-TVP-SP-XL
Price: 320.50 $
Specifications
| Brand | FAG |
| Item Number | NN3012-D-K-TVP-SP-XL FAG |
| Manufacturer Part Number | 0867008800000 |
| Also known as |
NN3012-D-K-TVP-SP |
| EAN | 4054369031454 |
| Category | Cylindrical Roller Bearing Double Row |
| Inner (d) MM | 60 |
| Outer (D) MM | 95 |
| Width (B) MM | 26 |
| Inner (d) Inch | 2.3622 |
| Outer (D) Inch | 3.7402 |
| Width (B) Inch | 1.0236 |
| Weight (kg) | 0.66 kg |
| Bore | K - 1:12 Tapered Bore (Standard for Most Types) |
| Seal | No Seal |
| Cage Type | P - Plastic Molded Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | SP - Precision Higher than P4S |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 26 |
| Radial Static Load Rating C0r (N) | 106000 |
| Radial Dynamic Load Rating Cr (N) | 87000 |
| Basic static load rating, radial (C 0r) | "106000.0000" |
| Fatigue load limit, radial (C ur) | 17400 |
| Limiting speed for grease lubrication (n G Grease) | 11300 |
| Limiting speed for oil lubrication (n G Oil) | 13300 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Super precision cylindrical roller bearings NN30..-K-TVP-SP, Non-locating bearing, double row, with tapered bore, taper 1:12, separable, with cage |
| D | Bearings With A Modified Internal Construction And The Suffix D Do Not Have A Lubrication Hole Or Lubrication Groove As Standard |
| K | Tapered Bore, Taper 1:12 |
| TVP | Moulded Polyamide Window-Type Cage, Rolling Element Riding |
| SP | Super Precision Specification, Tolerance Class SP, Radial Clearance C1 |
| XL | X-Life |
