FAG NJ409-XL-M1A-C4 Image 3
Visual product photo and picture of the product.
Price: 304.48 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
120 |
| Width (B) MM |
29 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
4.7244 |
| Width (B) Inch |
1.1417 |
| Weight (kg) |
1.67 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
No External Modification |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
29 |
| Basic static load rating, radial (C 0r) |
119000 |
| Limiting speed (n G) |
11000 |
| Reference speed (n u03d1r) |
5900 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
Suffix description
| XL |
X-Life |
| M1A |
Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring |
| C4 |
Bearing Internal Clearance Greater Than C3 |
