FAG NJ312-E-XL-M1A-C4

FAG NJ312-E-XL-M1A-C4
FAG NJ312-E-XL-M1A-C4 rulman resim 1
FAG NJ312-E-XL-M1A-C4 rulman resim 2
FAG NJ312-E-XL-M1A-C4 rulman resim 3
FAG NJ312-E-XL-M1A-C4 rulman resim 4
FAG NJ312-E-XL-M1A-C4 rulman resim 5
FAG NJ312-E-XL-M1A-C4 rulman resim 6
FAG NJ312-E-XL-M1A-C4 rulman resim 7
Price: 281.94 $
Specifications
Brand FAG
Item Number NJ312-E-XL-M1A-C4 FAG
Manufacturer Part Number 0382608910040
Also known as NJ312-E-M1A-C4
EAN 4026677036926
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 60
Outer (D) MM 130
Width (B) MM 31
Inner (d) Inch 2.3622
Outer (D) Inch 5.1181
Width (B) Inch 1.2205
Weight (kg) 2.11 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 31
Radial Static Load Rating C0r (N) 157000
Radial Dynamic Load Rating Cr (N) 177000
Basic static load rating, radial (C 0r) "157000.0000"
Limiting speed (n G) 9600
Reference speed (n u03d1r) 5200
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NJ..-E-XL-M1A, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ
Suffix description
E Increased Load Capacity
XL X-Life
M1A Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring
C4 Bearing Internal Clearance Greater Than C3
