FAG NJ310-E-XL-M1-C4

FAG NJ310-E-XL-M1-C4
FAG NJ310-E-XL-M1-C4 rulman resim 1
FAG NJ310-E-XL-M1-C4 rulman resim 2
FAG NJ310-E-XL-M1-C4 rulman resim 3
FAG NJ310-E-XL-M1-C4 rulman resim 4
Price: 180.44 $
Specifications
Brand FAG
Item Number NJ310-E-XL-M1-C4 FAG
Manufacturer Part Number 0190078500040
Also known as NJ310-E-M1-C4
EAN 4012801384360
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 110
Width (B) MM 27
Inner (d) Inch 1.9685
Outer (D) Inch 4.3307
Width (B) Inch 1.063
Weight (kg) 1.32 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 27
Radial Static Load Rating C0r (N) 114000
Radial Dynamic Load Rating Cr (N) 131000
Basic static load rating, radial (C 0r) "114000.0000"
Limiting speed (n G) 11600
Reference speed (n u03d1r) 6000
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NJ..-E-XL-M1, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ
Suffix description
E Increased Load Capacity
XL X-Life
M1 Solid Brass Cage, Two Piece, Roller Guided
C4 Bearing Internal Clearance Greater Than C3
