FAG NJ305-E-XL-M1-C4

FAG NJ305-E-XL-M1-C4
FAG NJ305-E-XL-M1-C4 rulman resim 1
FAG NJ305-E-XL-M1-C4 rulman resim 2
FAG NJ305-E-XL-M1-C4 rulman resim 3
Price: 83.28 $
Specifications
Brand FAG
Item Number NJ305-E-XL-M1-C4 FAG
Manufacturer Part Number 0190077870040
Also known as NJ305-E-M1-C4
EAN 4026677475954
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 62
Width (B) MM 17
Inner (d) Inch 0.9843
Outer (D) Inch 2.4409
Width (B) Inch 0.6693
Weight (kg) 0.293 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 17
Radial Static Load Rating C0r (N) 37500
Radial Dynamic Load Rating Cr (N) 49000
Basic static load rating, radial (C 0r) "37500.0000"
Limiting speed (n G) 21500
Reference speed (n u03d1r) 10100
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NJ..-E-XL-M1, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ
Suffix description
E Increased Load Capacity
XL X-Life
M1 Solid Brass Cage, Two Piece, Roller Guided
C4 Bearing Internal Clearance Greater Than C3
