FAG NJ2318-E-XL-MPAX-QP51-C4 Image 3
Visual product photo and picture of the product.
Price: 778.13 $
Specifications
Weight and Dimensions
| Inner (d) MM |
90 |
| Outer (D) MM |
190 |
| Width (B) MM |
64 |
| Inner (d) Inch |
3.5433 |
| Outer (D) Inch |
7.4803 |
| Width (B) Inch |
2.5197 |
| Weight (kg) |
9.1 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
No External Modification |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
QP - Vibrating Screen Specification |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Suffix description
| E |
Increased Load Capacity |
| XL |
X-Life |
| MPAX |
Rib-Guided Single-Piece Solid Brass Cage Is A Further Development Of FAG Cage Types MPA And MP1A And Will Replace These Types Successively. It Has Greater Durability With Regard To Shock Loads And Vibrations Than It's Predecessors And It's Especially Well Suited For Applications Involving High Loads |
| QP51 |
Vibrating Screen Specification |
| C4 |
Bearing Internal Clearance Greater Than C3 |
