FAG NJ2312-E-XL-M1A-QP51-C4 Image 3
Visual product photo and picture of the product.
Price: 334.51 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
130 |
| Width (B) MM |
46 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
5.1181 |
| Width (B) Inch |
1.811 |
| Weight (kg) |
3.113 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
No External Modification |
| Radial Internal Play |
C4 Internal Play (Higher than C3) |
| Precision |
QP - Vibrating Screen Specification |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
46 |
| Basic static load rating, radial (C 0r) |
260000 |
| Limiting speed (n G) |
9600 |
| Reference speed (n u03d1r) |
4250 |
Suffix description
| E |
Increased Load Capacity |
| XL |
X-Life |
| M1A |
Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring |
| QP51 |
Vibrating Screen Specification |
| C4 |
Bearing Internal Clearance Greater Than C3 |
