FAG NJ212-E-XL-M1-F1-C4

FAG NJ212-E-XL-M1-F1-C4
FAG NJ212-E-XL-M1-F1-C4 rulman resim 1
Price: 193.05 $
Specifications
Brand FAG
Item Number NJ212-E-XL-M1-F1-C4 FAG
Manufacturer Part Number 0390152890040
Also known as NJ212ECM/C4VA301
EAN 4026677903617
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 60
Outer (D) MM 110
Width (B) MM 22
Inner (d) Inch 2.3622
Outer (D) Inch 4.3307
Width (B) Inch 0.8661
Weight (kg) 0.947 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Bearings for Traction Motors
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 22
Basic static load rating, radial (C 0r) 103000
Limiting speed (n G) 11500
Reference speed (n u03d1r) 5300
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Suffix description
E Increased Load Capacity
XL X-Life
M1 Solid Brass Cage, Two Piece, Roller Guided
F1 FAG Manufacturing And Inspection Specification For Cylindrical Roller Bearings In Traction Motors Which Considers, Among Others, The Requirements According To Din 43283 "Cylindrical Roller Bearings For Electric Traction"
C4 Bearing Internal Clearance Greater Than C3
