FAG N324-E-XL-M1 Image 3
Visual product photo and picture of the product.
Price: 1,357.80 $
Specifications
Weight and Dimensions
| Inner (d) MM |
120 |
| Outer (D) MM |
260 |
| Width (B) MM |
55 |
| Inner (d) Inch |
4.7244 |
| Outer (D) Inch |
10.2362 |
| Width (B) Inch |
2.1654 |
| Weight (kg) |
15.2 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
55 |
| Radial Static Load Rating C0r (N) |
600000 |
| Radial Dynamic Load Rating Cr (N) |
610000 |
| Basic static load rating, radial (C 0r) |
"600000.0000" |
| Limiting speed for grease lubrication (n G Grease) |
3900 |
| Limiting speed for oil lubrication (n G Oil) |
4550 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
| Medias description |
Cylindrical roller bearing N3..-E-M1, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N3 |
Suffix description
| E |
Increased Load Capacity |
| XL |
X-Life |
| M1 |
Solid Brass Cage, Two Piece, Roller Guided |
