FAG N248-E-TB-M1-C3 Image 2
Visual product photo and picture of the product.
Price: 5,582.25 $
Specifications
Weight and Dimensions
| Inner (d) MM |
240 |
| Outer (D) MM |
440 |
| Width (B) MM |
72 |
| Inner (d) Inch |
9.4488 |
| Outer (D) Inch |
17.3228 |
| Width (B) Inch |
2.8346 |
| Weight (kg) |
51.5 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
M - Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Width (b) mm |
72 |
| Basic static load rating, radial (C 0r) |
1650000 |
| Limiting speed for grease lubrication (n G Grease) |
1980 |
| Limiting speed for oil lubrication (n G Oil) |
2320 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
Suffix description
| E |
Increased Load Capacity |
| TB |
The Rollers Have A Special Crowning On The Side Surface. Is Not Depending On The Cage Design. The Result Is A Better Lubrication In Between Roller And Rim |
| M1 |
Solid Brass Cage, Two Piece, Roller Guided |
| C3 |
Internal Clearance Larger Than Normal |
