FAG HSS71918-E-T-P4S-K5-DBL Image 2
Visual product photo and picture of the product.
Price: 1,251.79 $
Specifications
Weight and Dimensions
| Inner (d) MM |
90 |
| Outer (D) MM |
125 |
| Width (B) MM |
36 |
| Inner (d) Inch |
3.5433 |
| Outer (D) Inch |
4.9213 |
| Width (B) Inch |
1.4173 |
| Weight (kg) |
1.18 kg
|
Product Properties
| Seal |
2RU - Two Seals / Non Contact Type |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
K5 - P4S + K5 |
| Contact Angle |
25 degrees |
| Pairing |
DB - O-arrangement, 2 |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
18 |
| Basic static load rating, radial (C 0r) |
17700 |
| Limiting speed for grease lubrication (n G Grease) |
13000 |
Suffix description
| E |
25° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S-K5 |
Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| DBL |
Set Of 2 Bearings O-Arrangement, Light Preload |
