FAG HS7005-C-T-P4S-DUL Image 4
Visual product photo and picture of the product.
Price: 261.15 $
Specifications
Weight and Dimensions
| Inner (d) MM |
25 |
| Outer (D) MM |
47 |
| Width (B) MM |
24 |
| Inner (d) Inch |
0.9843 |
| Outer (D) Inch |
1.8504 |
| Width (B) Inch |
0.9449 |
| Weight (kg) |
0.16 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4S Precision (Higher than P4) |
| Contact Angle |
15 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
DL - 2 Univ Bearings Light Preload |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
12 |
| Radial Static Load Rating C0r (N) |
3000 |
| Radial Dynamic Load Rating Cr (N) |
5800 |
| Basic static load rating, radial (C 0r) |
"3000.0000" |
| Limiting speed for grease lubrication (n G Grease) |
45000 |
| Limiting speed for oil lubrication (n G Oil) |
70000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Spindle bearings HS70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances |
Suffix description
| C |
15° Or 17° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL |
Set Of 2 Universal Bearings, Light Preload |
