FAG HCS71912-E-T-P4S-N16-DTL Image 3
Visual product photo and picture of the product.
Price: 1,084.97 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
85 |
| Width (B) MM |
26 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
3.3465 |
| Width (B) Inch |
1.0236 |
| Weight (kg) |
0.38 kg
|
Product Properties
| Seal |
2RU - Two Seals / Non Contact Type |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4S Precision (Higher than P4) |
| Contact Angle |
25 degrees |
| Pairing |
DT - Tandem Arrangement, 2 |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
13 |
| Basic static load rating, radial (C 0r) |
8300 |
| Limiting speed for grease lubrication (n G Grease) |
26000 |
Suffix description
| E |
25° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| N16 |
|
| DT |
Set Of 2 Bearings Tandem Arrangement |
| L |
Light Preload |
