FAG HCB7209-E-T-P4S-UL

FAG HCB7209-E-T-P4S-UL
FAG HCB7209-E-T-P4S-UL rulman resim 1
FAG HCB7209-E-T-P4S-UL rulman resim 2
FAG HCB7209-E-T-P4S-UL rulman resim 3
Price: 515.57 $
Specifications
Brand FAG
Item Number HCB7209-E-T-P4S-UL FAG
Manufacturer Part Number 0387936520000
EAN 4026677681492
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 85
Width (B) MM 19
Inner (d) Inch 1.7717
Outer (D) Inch 3.3465
Width (B) Inch 0.748
Weight (kg) 0.369 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 19
Radial Static Load Rating C0r (N) 16200
Radial Dynamic Load Rating Cr (N) 32500
Basic static load rating, radial (C 0r) "16200.0000"
Limiting speed for grease lubrication (n G Grease) 18000
Limiting speed for oil lubrication (n G Oil) 30000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings HCB72..-E, adjusted, in pairs or sets, contact angle a = 25°, with ceramic balls, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
