FAG HCB7020-EDLR-T-P4S-UL Image 3
Visual product photo and picture of the product.
Price: 1,508.08 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Outer (D) MM |
150 |
| Width (B) MM |
24 |
| Inner (d) Inch |
3.937 |
| Outer (D) Inch |
5.9055 |
| Width (B) Inch |
0.9449 |
| Weight (kg) |
1.04 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4S Precision (Higher than P4) |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
DLR |
Data from Schaeffler (medias)
| Width (b) mm |
24 |
| Radial Static Load Rating C0r (N) |
52000 |
| Radial Dynamic Load Rating Cr (N) |
79000 |
| Limiting speed for grease lubrication (n G Grease) |
11000 |
| Limiting speed for oil lubrication (n G Oil) |
17000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Spindle bearings HCB70..-EDLR, adjusted, matched pairs or sets, contact angle a = 25°, with ceramic balls, restricted tolerances, for direct oil feed via outer ring, with inserted O rings |
Suffix description
| E |
25° Contact Angle |
| DLR |
Direct Lube, Integral O-Ring |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL |
Single Bearing, Universal, Light Preload |
