FAG BAX100-F-T-P4S-DBL Image 2
Visual product photo and picture of the product.
Price: 1,252.04 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Outer (D) MM |
150 |
| Width (B) MM |
45 |
| Inner (d) Inch |
3.937 |
| Outer (D) Inch |
5.9055 |
| Width (B) Inch |
1.7717 |
| Weight (kg) |
2.52 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4S Precision (Higher than P4) |
| Contact Angle |
30 degrees |
| Pairing |
DB - O-arrangement, 2 |
| Axial Internal Clearance / Preload |
GA - Light Preload |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (2B) mm |
45 |
| Axial Static Load Rating C0a (N) |
118000 |
| Axial Dynamic Load Rating Ca (N) |
52000 |
| Limiting speed for grease lubrication (n G Grease) |
6300 |
| Limiting speed for oil lubrication (n G Oil) |
9000 |
| ECLASS number |
23-05-10-02 |
| ECLASS2 number |
23-05-10-02 |
| Medias description |
Angular contact ball bearing BAX..-F-T-P4S-DBL |
Suffix description
| F |
30° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DBL |
Set Of 2 Bearings O-Arrangement, Light Preload |
