FAG B7224-C-T-P4S-UL Image 2
Visual product photo and picture of the product.
Price: 1,015.18 $
Specifications
Weight and Dimensions
| Inner (d) MM |
120 |
| Outer (D) MM |
215 |
| Width (B) MM |
40 |
| Inner (d) Inch |
4.7244 |
| Outer (D) Inch |
8.4646 |
| Width (B) Inch |
1.5748 |
| Weight (kg) |
5.29 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4S Precision (Higher than P4) |
| Contact Angle |
15 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
40 |
| Radial Static Load Rating C0r (N) |
138000 |
| Radial Dynamic Load Rating Cr (N) |
205000 |
| Basic static load rating, radial (C 0r) |
"138000.0000" |
| Limiting speed for grease lubrication (n G Grease) |
6000 |
| Limiting speed for oil lubrication (n G Oil) |
9000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Spindle bearings B72..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances |
Suffix description
| C |
15° Or 17° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL |
Single Bearing, Universal, Light Preload |
